Small Fire Alarm Project Shop Drawings

Small fire alarm projects are those who's scope of work encompasses 10 or fewer devices. Examples of a small fire alarm project:

• Sprinkler monitor system installs
• Radio communicator change-outs
• Minor system modifications

In order to begin your project we will contact you to collect the following information:

• Architectural plans of the building/area of work
• Any relevant pre-existing fire alarm, mechanical and electrical plans for the property
• Job "takeoff" detailing the fire alarm work that will be performed, device types and locations, preferred manufacturers and other pertinent system details

• Occupancy and AHJ details

You can expect completion of your small fire project within 5 business days. Completed plan sets will always include:

• Floor plans with device locations
• Alarm riser diagrams
• Battery load and voltage drop calculations
• Conductor specs
• BOM
• Sequence of operation details

• Device spec sheets

Projects include one plan revision, additional revisions are billed at $50 each.

(Physical plan delivery will be sent via USPS unless requested otherwise)
